BASIC HELP : MS4BI Designer by MS4script
   2021 version 1

INPUT SELECT

Definition

To declare an input variable along with a selection button

Update or Delete cycle: use the selection button to select the record to be updated or deleted

Insert cycle: use the selection button to select a repository for the table referenced in the InputSelect variable

Syntax


 <InputSelect  : type="text"  name="NAME" like : table("People")  class=standardMs4  placeholder="please select-MONTH-"   >;
  <button + GetSelectPop()   :  $Bts_btn_success_btn_sm  ,  icon   :  $fa_1x + $fa_search  , text : "Select" > ;

KEYWORD :
BEGIN_FORM inputselect,Inputdata...Submit()... END_FORM


Begin_transaction ; nameTRS
  cycle : insert table xxxx, update table xzzzzn delete Row table xx..
  begin_form
   inputselect  var1 ..InputSel.. var2..submit
   End_form ;
       Chart or dashboard or image or grid....
  End_transaction ;

Method and Settings option

Example 1


 Begin_TransactionWeb : "02-DataEditADD" ,
    Cycle :
   Insert :  table "people" ;
  
Begin_FormWeb ** INSERT
   position:position:2585,282,40,124 :
  <InputSelect  type="text" name="NAME" like : table("people") class=standardMs4 placeholder="please select-NAME-"   >;
   position:position:2587,418,auto,auto :
  <button + GetSelectPop()  :  $Bts_btn_success_btn_sm  ,  icon   :  $fa_1x + $fa_search  , text : "Select" > ;
   position:position:2642,287,41,142 :
  <InputSelect   type="text" name="FIRSTNAME"  like : table("people") class=standardMs4 placeholder="please select-FIRSTNAME-"   >;
   position:position:2644,441,auto,auto :
  <button + GetSelectPop()  :  $Bts_btn_success_btn_sm  ,  icon   :  $fa_1x + $fa_search  , text : "Select" > ;
   position:position:2702,289,31,90 :
  <InputSelect    type="text"  name="SEX"    like : table("people") class=standardMs4 placeholder="please select-SEX-"   >;
   position:position:2704,391,auto,auto :
  <button + GetSelectPop()  :  $Bts_btn_success_btn_sm  ,  icon   :  $fa_1x + $fa_search  , text : "Select" > ;
   position:position:2742,288,35,135 :
  <InputData:   type="int"  name="AGE"     like : table("people") class=standardMs4       placeholder="-AGE-"  >;
   position:position:2834,270,74,144 :
  <InputData:   type=SubmitForm()   class="btn btn-lg btn-primary"  attrib="value='Submit (ADD)' "  >;
  
 End_FormWeb ;
    ....


IMPLEMENTATION
